24H Automatic copper tubular annealing machine (24 wires)

The Tubular Annealing Tinning Machine is composed of a heat-treatment unit, a pickling bath, a tin furnace, lead rollers, and a wire take-up device. This equipment is capable of continuously annealing and softening 24 copper wires with diameters ranging from 0.10 to 0.80 mm.

Get A Quote

Parameter
Contact Us

1. Twenty - four copper wires are softened simultaneously, enhancing production output and efficiency.

2. The machine is equipped with a uniform - temperature - distribution system, demonstrating excellent energy-saving performance.

3. An independent traversing motor is installed.

4. The double-layer coiling design reduces the equipment's footprint.

5. The machine ensures uniform temperature and a good annealing effect.

Production speed:	100MPM/MAX
Pay-off spool dimension:	Φ200mm /Max (according to customer’s requirements)
Heating power of annealing furnace:	59.4KW
Roller leading:	Double inverter and motor control; power; 2.2KW-4P*2
Wire number:	24pcs/max. on pay-off & annealing, 20 pcs/max. on take-up machine.
Take-up spools:	DIN125, DIN160, DIN200 (according to customer’s requirements)
Machine weight:	10000kgs
